Slide & Tilt Hardware
MACO slide&tilt hardware for ceiling-height, large-format elements with a sash weight up to 200 kg in PVC, timber, and timber-aluminium never fails to impress with its consistent operating convenience and security. Three system versions are available with standardised basic hardware for the central locking system, optionally available in our extremely corrosion-resistant TRICOAT-Plus surface finish. All three systems are easy to install and vertical adjustment of the roller is a breeze.
RAIL-SYSTEMS Slide ＆ Tilt Hardware - MACO SLIDING DOORS
SKB-S – standard system
The hardware with manual opening and closing function is used on PVC, timber and timber-aluminium with a sash weight of up to 160 kg. The stop width is 125 mm. This enables the use of wide sash profiles, which means that even triple glazing is not a problem. The lead-in curve is 53 mm and offers the same benefit. The frame clearance, which is set at 35 mm, reduces the sill height and provides effortless exit and entry thanks to the level passage surface. It also does away with the need for costly double profiles. Depending on the individual unit equipment from the door producer, the slide&tilt solution is RC-2 and CE-compatible. The height of the roller can be adjusted with a TX spanner. A complete jig range is available.
SKB-Z – Positive Control System
In this system for slide&tilt doors up to 200 kg made of PVC, timber, or timber-aluminium, the automatic opening and closing function is controlled centrally via the handle lever. A mishandling device can be optionally integrated. If the handle is in the opening position, the anti lock-out device prevents the sash from unintentional closing. The standard hardware is equipped with the i.S. security roller cam. This provides burglary protection, optimises the gasket compression setting and automatically compensates the air gap. A tandem roller is available for use above a sash weight of 160 kg.
SKB-S – standard system
The hardware with manual opening and closing function is used on PVC, timber and timber-aluminium with a sash weight of up to 160 kg. The stop width is 125 mm. This enables the use of wide sash profiles, which means that even triple glazing is not a problem. The lead-in curve is 53 mm and offers the same benefit. The frame clearance, which is set at 35 mm, reduces the sill height and provides effortless exit and entry thanks to the level passage surface. It also does away with the need for costly double profiles. Depending on the individual unit equipment from the door producer, the slide&tilt solution is RC-2 and CE-compatible. The height of the roller can be adjusted with a TX spanner. A complete jig range is available.
